Exclusive value with the Allen & Heath Qu-24C digital mixer and GLD-AR2412 stage box ,Mixing Made Simple

Take Complete Control of Your Live Sound

Professional sound demands more than just great equipment—it requires control, flexibility and reliable performance. The Allen & Heath Qu-24C with AR2412 Audio Rack delivers a complete digital mixing solution designed for demanding live sound environments.

Combining the intuitive Qu-24C digital mixing console with the powerful AR2412 stagebox, this exclusive bundle gives sound engineers everything they need to manage complex productions with confidence.

Whether you are mixing for a church, live venue, studio, event company, theatre or AV installation, this system provides professional-quality audio with an efficient and organised setup.

Professional Digital Mixing Made Simple

The Allen & Heath Qu-24C combines advanced digital mixing technology with a familiar, hands-on control surface.

Its 25 motorised faders, responsive 5-inch colour touchscreen and dedicated physical controls allow engineers to work quickly without navigating complicated menus.

The Qu-24C provides:

• 24 mono mic/line input channels
• 3 stereo input channels
• 25 motorised faders
• 5-inch colour touchscreen
• 20 mix outputs
• 4 DCA groups
• 4 mute groups
• 10 programmable SoftKeys
• Automatic Mic Mixing
• Scene recall and user permissions

From small events to full professional productions, the Qu-24C gives you the control required to create clear, balanced and powerful mixes.

Expand Your System with the AR2412 Audio Rack

The included Allen & Heath AR2412 Audio Rack expands your system with 24 remote XLR mic/line inputs and 12 balanced XLR outputs.

Instead of running multiple analogue cables between the stage and the mixing position, the AR2412 connects to the Qu-24C using a single Cat5e cable through Allen & Heath’s dSNAKE system.

This allows you to position the audio rack directly on or near the stage, providing a cleaner and more professional installation.

The AR2412 includes:

• 24 XLR mic/line inputs
• 12 balanced XLR line outputs
• Remote-controlled microphone preamps
• 48kHz operation
• dSNAKE connectivity
• Expander port for compatible additional I/O
• Monitor port for Allen & Heath ME personal monitoring systems
• 3U 19-inch rackmount design

The AR2412 can be positioned up to 100 metres away from the mixer, making it ideal for large venues, churches, stages and event spaces.

Record Every Performance

The Qu-24C offers built-in Qu-Drive recording, allowing you to capture stereo or multitrack audio directly to a compatible USB drive.

This is ideal for:

• Recording live performances
• Capturing church services
• Creating rehearsal recordings
• Producing virtual soundchecks
• Archiving important events
• Preparing material for post-production

The console can also function as a 32-output and 30-input USB audio interface for Mac and Windows computers, making it suitable for both live recording and studio production.

Built-In Effects and Processing

The Qu-24C includes four stereo FX engines, giving engineers access to professional-quality processing without requiring additional external equipment.

Its onboard processing helps you shape and control every channel while keeping your equipment setup compact and efficient.

Create polished vocal mixes, controlled instrument channels and professional effects directly from the console.

Save and Recall Your Settings

Scene recall allows engineers to save complete mixer configurations and load them again whenever needed.

This is especially useful for:

• Churches with multiple services
• Venues hosting different performers
• Schools and theatres
• Touring productions
• Corporate events
• Installations operated by different users

User permissions can also be configured to control which functions are available to different operators, helping protect important settings from accidental changes.

Ideal For

The Allen & Heath Qu-24C with AR2412 Audio Rack is ideal for:

• Churches and houses of worship
• Live music venues
• Event production companies
• Professional sound engineers
• Theatres and schools
• Recording studios
• Corporate AV systems
• Rental companies
• Conference venues
• Permanent sound installations

Whether you are upgrading an existing analogue system or building a complete digital setup, this bundle gives you the flexibility and connectivity required for professional sound production.

A Complete Professional Mixing Solution

The Allen & Heath Qu-24C and AR2412 Audio Rack work together to provide powerful digital mixing, remote stage connectivity and professional recording capabilities.

With 24 remote inputs, 12 remote outputs, motorised faders, touchscreen control, built-in effects and multitrack recording, this bundle is designed to handle everything from weekly services to demanding live productions.

Available from A1 Sound

Take your live sound system to the next level with the Allen & Heath Qu-24C and AR2412 Audio Rack exclusive bundle.

Mix with confidence. Simplify your setup. Deliver professional sound.
