AT-OME-RX11 HDBaseT Receiver With Audio De-Embedding

The Atlona AT-OME-RX21 is a HDBaseT receiver with integrated USB extension, designed for use with Atlona OMEGA Series transmitters and presentation switchers. It receives video, audio, USB, Ethernet, and control signals over a single category cable and outputs them locally via HDMI.

This receiver is commonly used in conference rooms, collaboration spaces, and classrooms, where USB conferencing devices such as cameras, microphones, and speakerphones need to connect to a laptop at the meeting table through the AV system.

Key Features

• HDBaseT receiver with USB extension

• Supports 4K/UHD up to 4K/60 4:2:0

• Transmission distance up to 70 m over Cat6a/7 cable

• HDCP 2.2 compliant

• USB 2.0 extension for conferencing peripherals

• RS-232 and IR pass-through

• Ethernet extension over HDBaseT

• Compact design for behind-display installation

Technical Specifications

Video

• HDBaseT Input: 1 × RJ45

• HDMI Output: 1 × HDMI Type-A

• Maximum Resolution: 4K/UHD @ 60 Hz (4:2:0)

• HDCP: HDCP 2.2 compliant

USB

• USB Host Port: 1 × USB-B

• USB Device Ports: 2 × USB-A

• Supports USB 2.0 extension

Transmission

• Technology: HDBaseT

• Maximum Distance:

  • 70 m for 1080p

  • 40 m for 4K

• Cable Type: Cat6a / Cat7

Control

• RS-232 pass-through

• IR pass-through

• Ethernet extension

Power

• Powered via PoE from compatible Atlona transmitter
