Audac AUA-AXIR/OB Outdoor Design Column Speaker 12 x 2 Black Version

The Audac AXIR/OB is an infrared receiver module designed for use with compatible Audac audio systems that support IR remote control functionality. It receives commands from infrared remote controllers and transmits them to connected audio equipment, enabling convenient remote operation.

The outdoor (OB) version is designed for installations where the receiver may be exposed to outdoor environments or more demanding conditions. Its robust construction ensures reliable reception of IR signals in outdoor hospitality areas, terraces, commercial venues, and public installations.

This receiver is commonly used in distributed audio systems to allow users to control volume, source selection, and other system functions remotely.

Key Features

• Infrared receiver module for remote system control
• Designed for outdoor installation environments
• Compatible with Audac systems supporting IR control
• Compact and discreet design for installation
• Reliable signal reception for professional AV systems

System Specifications

Speaker type: Broadband column

Power Handling

Power Rating (RMS / AES): 120 W
Program power handling: 240 W
Peak power handling: 480 W

Impedance

6 Ω

Line Transformer Tappings

2 × 20 W – 500 Ω
2 × 10 W – 1000 Ω
2 × 5 W – 2000 Ω
2 × 2.5 W – 4000 Ω

Sensitivity

92 dB (1 W / 1 m)

Maximum Sound Pressure Level

113 dB

Applications

• Outdoor hospitality venues
• Retail and commercial audio installations
• Restaurants and cafés
• Conference and meeting rooms
• Public address systems
