Audac AUA-CMX230 Shotgun Condenser Microphone

The Audac AUA-CMX230 is a professional shotgun condenser microphone designed for highly directional voice capture in environments where background noise control is critical. Ideal for conference rooms, lecterns, broadcast setups, houses of worship, and paging systems, this microphone delivers focused pickup with excellent speech intelligibility.

Its supercardioid / lobar pickup pattern ensures precise sound capture from the front while rejecting off-axis noise, making it perfect for installations where clarity and isolation are essential. The slim and discreet design allows clean integration into professional audio setups.

Powered via phantom power and equipped with a standard 3-pin XLR connector, the CMX230 integrates seamlessly with mixers, DSP systems, and installed audio solutions.

Key Features

• 30 cm shotgun condenser microphone
• Highly directional (supercardioid / lobar) pickup pattern
• Excellent off-axis noise rejection
• Clear and focused speech reproduction
• Slim and discreet installation design
• 3-pin XLR output connection
• Phantom powered operation
• Ideal for conferencing, broadcast, lecterns, and worship environments

Specifications

• Microphone type: Back electret condenser
• Polar pattern: Supercardioid / lobar
• Frequency response: 50 Hz – 18 kHz
• Sensitivity: -45 dB ± 3 dB / Pa at 1 kHz
• Impedance: 200 Ω ± 30%
• Signal-to-noise ratio: 75 dB
• Maximum SPL: 130 dB
• Power supply: 10 – 52V DC phantom power
• Connector: 3-pin XLR
