The COMBINE8 IEM combiner brings together up to eight in-ear monitor transmitter signals into a single, more powerful transmit antenna, eliminating the use of problematic multiple antennas while lowering the buildup of unwanted Intermodulation.
Features
- 8 IEM Transmitter Signals into 1 Antenna
- Any Brand IEM Transmitter 50mW or Less
- Any Type of Directional Antenna
- DC Power Supply for 8 Transmitters
Specs
| Frequency Range |
407 to 608 MHz
|
| I/O |
8 x BNC RF Input Connectors
1 x BNC Antenna Output Connector |
| Gain |
Full System Gain: 0 dB (±2 dB)
|
| Maximum RF Input Power |
+18 dBm (60 mW)
|
| LED Indicator |
Input Signal Threshold: > +5 dBm
|
| Power Consumption |
36 W
|
| Power |
Input AC: 100-240 VAC, 50/60 Hz, 1.5 A (Maximum)
|
| Dimensions |
18.9 x 1.8 x 10.2″ / 480 x 45 x 260 mm
|
| Weight |
8.1 lb / 3.7 kg
|
