- Specifications
| Type | Single 12” Full Range DSP-Controlled |
| Frequency Response (-10dB) | 55 Hz – 20 kHz |
| Horizontal Coverage (Symmetrical | 90 ° |
| Vertical Coverage | 60 ° |
| Maximum Calculated SPL/1m | |
| Continuous | 122 dB |
| Program | 125 dB |
| Peak | 128 dB |
| Drivers | |
| HF | Customised Ferrite Driver, 1.4″ Voice Coil, 1.0″ Exit |
| LF | 12″ Woofer, 2.0″ Voice Coil |
| DSP | |
| Processor | 48 kHz Signal Sampling Frequency |
| Presets | Music; Flat; Speech |
| Amplifier | |
| Amplifier | Class D |
| Power (RMS Standard) | 800 W |
| Peak Power | 1600 W |
| Frequency Response (1 W 8, 2 ch) | 20 Hz – 20 kHz (± 0.5 dB) |
| Intermodulation Distortion | ≤0.05% |
| Total harmonic distortion | ≤0.05% |
| Cooling | Cooling with fan |
| Protection | |
| Short Circuit Protection | Yes |
| Output Overload Protection | – |
| Soft Startup Protection | Yes |
| Over-Temperature Protection | Yes |
| Undervoltage Protection | – |
| Signal Input Connector | 2 X Female XLR (Mono Jack 6.35); 1 X AUX Input; 1 X Wireless Bluetooth |
| Signal Output Connector | Male XLR Line / MIX Output |
| Power Input | IEC Power Connector |
| Working Voltage | 220-240 V ~ (±0%, 50/60 Hz) |
| Power Consumption (1/8 Output Power) | 55 W |
| Cabinet | |
| Material | New PP Composite Material |
| Painting | Plastic Cabinet |
| Colour | Black |
| Grille | Iron Mesh |
| Handle | 1 X Top; 1 X Side |
| Monitor Angle | Symmetrical 45 ° Monitor Angle |
| Hanging Hardware | M8 Screw |
| Pole Mount | Bass Hole 35 mm (Diameter) |
| Selectable Accessory | Wall Mount Bracket; Protective Bag; Adjustable Coupling Bar |
| Speaker Dimensions (W X H X D) | 381 X 582 X 343 mm |
| Carton Dimensions (W X H X D) | 426 X 665 X 401 mm |
| Net Weight | 14 kg |
| Gross Weight | 17 kg |
