AudioCenter PD1000 4-channel Power Amplifier

Name: AudioCenter PD1000 4-channel Power Amplifier - A1 Sound
Brand: Audio Center
SKU: PD1000
Price: 14310.00 ZAR
Availability: InStock

SKU: PD1000 Brand: Audio Center

R14 310,00

In stock (can be backordered)

Attribute	Value
Number of Channels	4
Power Output at 8 Ohms Per Channel:	4x 1000W
Power Output at 4 Ohms Per Channel:	4x 1500W
Power Output at 2 Ohms Per Channel:	4x 1000W
Amplifier Class:	H
Shipping Weight:	27
Bridge Mode Power	2x 2000W

Compare

10 People watching this product now!

Description

AudioCenter PD1000 Professional Four-channel Power Amplifier

Overview

PD1000 is a professional four-channel power amplifier with high technology, premium sound performance and comprehensive protection system. It is a truly high-quality professional power amplifier.

PD1000 suitable for professional entertainers with limited budgets but demanding the best performance. It is widely used in bars, nightclubs, multi function halls, museums, religious places, speeches, weddings and other fixed installation and mobile performance venues.

Specifications

Output Power(1kHz, THD+N =1%)	4x 1000W @8Ω stereo 4x 1500W @4Ω stereo 4x 1000W @2Ω stereo 2x 3000W @8Ω bridge 2x 2000W @4Ω bridge
Protection	DC protection/Short circuit protection/ Smart overheat management/Overheat protection/Output overload protection / Soft startup protection/Limiter protection
Working mode	Stereo/Parallel/Bridge
Crossover(High Pass/Low Pass)	120Hz,-3dB
Input Connectors	Male XLR & Female XLR
Output Connectors	Speakon 4Pin
Input Impedance	≥20kΩ(Balanced),≥10kΩ(Unbalanced)
Maximum input voltage	≥20dBu
Sensitivity	0.775V / 36dB / 32dB
Frequency Response(1W 8Ω stereo)	20Hz-20kHz(± 1dB)
Crosstalk (1kHz, Rated power 8Ω A weighted)	≥60dB
S/N Ratio(Rated power 8Ω, A weighted)	≥100dB
Damping Factor (1kHz & 8Ω)	≥400
Intermodulation Distortion(60Hz:7kHz=4:1,half power)	≤0.1%
THD+N (1kHz,8Ω half power A weighted)	≤0.05%
Output Circuitry	Class H
Power Supply	100-130V~/220-240V~(±10%,50/60Hz)
Power Consumption(1/8 output power)	1680W
Rack Space	2U
Cooling	Back to front venting, mandatory cooling
Dimension (W×H×D)	483×88×457mm
Net Weight	27.0 kg
