The Phantom Laser Series are characterized by the compact design and the guaranteed output power. These show lasers provides an analogue modulation what results in a better colour fading and a much broader colour. The lasers can be controlled over ILDA and DMX or run stand-alone in auto or sound activated mode. You can produce the exact effect you want with the DMX and ILDA control. Ideal for any kind of application – fixed installations, mobile use, multimedia projects, long distance outdoor applications and extra precise graphics projections.
Features:
- Red (700mW), Green (700mW) and Blue (1600mW) Powerful laser
- Guaranteed 3W output
- Analog RGB colour modulation
- 25K @ 8° high speed optical scanner system
- X- and Y-Size inverter
- DMX and Stand-alone mode
- 12 or 23 DMX channels
- Master/slave function
- Sound activated or auto mode
- Pre-programmed shows
- DMX in/output via 3-pin XLR
- Ilda in/output
- Control panel with LED display
- Interlock
- Powerconnector in/output
Specifications:
- Input Connections: XLR (3-pin)
- Output connections: XLR (3-pin)
- DMX channels: 12, 23
- DMX connector: 3-pin XLR
- ILDA Connector: DB25
- Laser Red: 700mW @ 638nm
- Laser Green: 700mW @ 525nm
- Laser Blue: 1600mW @ 455nm
- Scanner system: 25kpps @ 8°
- Maximum scanner: angle 60 degrees
- Guaranteed output: 3W
- Power supply: 100-240VAC 50/60Hz
- Dimensions (L x W x H): 238 x 192 x 114mm (without bracket)
- Weight: 4.2kg
