Technical Specifications
-
Throat Diameter: 25.4 mm (1 in)
-
Rated Impedance: 8 Ω
-
Minimum Impedance: 5.3 Ω
-
DC Resistance: 4.5 Ω
-
Power Capacity (AES): 70 W above 1.8 kHz
-
Program Power: 140 W above 1.8 kHz
-
Sensitivity: 110 dB (1 W/1 m, coupled to TD-164 horn, averaged 2–7 kHz)
-
Frequency Range: 0.9 – 20 kHz
-
Recommended Crossover: 1.8 kHz or higher (12 dB/octave min.)
-
Voice Coil Diameter: 38.1 mm (1.5 in)
-
Flux Density: 1.6 T
-
Bl Factor: 6 N/A
Dimensions & Mounting
-
Overall Diameter: 102 mm (4.01 in)
-
Depth: 44.4 mm (1.75 in)
-
Mounting Options:
-
3 × M5 threaded holes, 120° apart, on 57 mm (2.24 in) bolt circle
-
2 × M5 threaded holes, 180° apart, on 76.2 mm (3 in) bolt circle
-
-
Net Weight: 1.3 kg (2.8 lb)
-
Shipping Weight: 1.4 kg (3 lb)
