Technical Specifications
-
Throat Diameter: 25.4 mm (1 in)
-
Horizontal Beamwidth: 60° (+10°, –5°) (–6 dB, 2–16 kHz)
-
Vertical Beamwidth: 40° (+31°, –2°) (–6 dB, 3–16 kHz)
-
Directivity Factor (Q): 14.1 (avg. 0.8–16 kHz)
-
Directivity Index (DI): 11 dB (+2 / –6.4 dB)
-
Cut-off Frequency: 1,200 Hz
-
Dimensions (W × H × D): 202 × 202 × 145 mm (7.95 × 7.95 × 5.71 in)
-
Cut-out Dimensions (W × H): 177 × 177 mm (6.97 × 6.97 in)
-
Net Weight: 1.0 kg (2.2 lb)
-
Shipping Weight: 1.3 kg (2.87 lb)
-
Material: Cast aluminium
