Technical Specifications
-
Throat Diameter: 25.4 mm (1 in)
-
Nominal Coverage: 90° (H) × 60° (V)
-
Directivity Index (DI): 8.8 dB
-
Cut-off Frequency: 1,500 Hz
-
Material: Reinforced Polycarbonate
Mounting Information
-
Dimensions (W × H × D): 160 × 160 × 100 mm (6.3 × 6.3 × 3.9 in)
-
Cut-out Dimensions (W × H): 139 × 139 mm (5.48 × 5.48 in)
-
Compression Driver Mounting:
-
3 × M5 holes, 120° apart on 57 mm (2.24 in) diameter
-
4 × M5 holes, 90° apart on 76.2 mm (3 in) diameter
-
-
Net Weight: 0.28 kg
-
Shipping Weight: 0.48 kg
