Technical Specifications
-
Throat Diameter: 36 mm (1.4 in)
-
Horizontal Beamwidth: 80° (+16°, –32°) (–6 dB, 1–20 kHz)
-
Vertical Beamwidth: 50° (+29°, –14°) (–6 dB, 1.6–20 kHz)
-
Directivity Factor (Q): 12.4 (avg. 0.63–16 kHz)
-
Directivity Index (DI): 10.5 dB (+3.5 / –3.2 dB)
-
Cut-off Frequency: 800 Hz
-
Dimensions (W × H × D): 235 × 235 × 120 mm (9.25 × 9.25 × 4.72 in)
-
Cut-out Dimensions (W × H): 204 × 202 mm (8.03 × 7.95 in)
-
Net Weight: 1.2 kg (2.64 lb)
-
Shipping Weight: 1.53 kg (3.37 lb)
-
Material: Cast aluminium
-
Driver Mounting: 4 screws on 101.6 mm diameter bolt circle
