FEATURES
- Maintain consistent tonal quality with shared voicing across all FS models
- Hear the best of both — music and voice — with transducers that offer clear voice reproduction and smooth response for background music
- Customize systems with confidence using in-ceiling, surface-mount, and pendant-mount options, allowing for tailored mix-and-match installations. DesignMax subwoofers and larger models can expand your system design options even further
- Blend with more room designs with updated enclosures — available in black and white — that pair modern aesthetics with practical features, including removable logos
- Tackle site-specific challenges with the support of a full suite of accessories, designed to handle a wide range of applications and mounting options
- Install with ease — all models feature Euroblock inputs and front-baffle input location on in-ceiling models
- Support public safety — EN54-24 for Voice Alarm Systems for Fire Detection and Fire Alarm Systems for Buildings
SPECS
Technical Specification
COMPLIANCE
- EN 54-24 Certified
- Yes
- Safety Agency Ratings
- EN 54-24:2008 for Voice Alarm Systems; UL 1480(A); in compliance with UL 2043 for plenum-space installation; NFPA 70 & NFPA 72; CSA C22.1 Section 32
PHYSICAL
- Colors
- Black (similar to RAL 9005), white (similar to RAL 9003)
- Enclosure Material
- Engineered-plastics front baffle with integrated steel-formed backcan
- Environmental
- Indoor only, suitable for use in plenum locations
- Grille
- Perforated steel, powder-coated finish
- Ceiling Cutout
- 6.3 in (160 mm)
- Logo
- Rotatable, removable
- Suspension/Mounting
- (2) mounting arms, (1) safety cable attachment point
- Operating Temperature Range
- 0 °C to 50 °C (32 °F to 122 °F)
- Product Dimensions (H×W×D)
- 7.2 in × 5.2 in (182 mm × 132 mm), loudspeaker diameter × depth / 5.0 in × 4.9 in (127 × 125 mm), backcan diameter × depth
- Net Weight
- 3.6 lb (1.6 kg), loudspeaker with grille (single)
- Shipping Weight
- 9.7 lb (4.4 kg), pair
PERFORMANCE
- Frequency Range (-10 dB)
- 83 – 19,000 Hz
- Coverage, Horizontal
- 150°
- Calculated Maximum SPL @ 1 m
- 98 dB
- Nominal Impedance
- 16 Ω (transformer bypass)
- Power Handling, long-term continuous
- 16 W
- Power Handling, Peak
- 64 W
- Sensitivity (SPL/1 W at 1 m)
- 86 dB
- Transformer Taps, 100V
- 2, 4, 8, 16 W, bypass
- Transformer Taps, 70V
- 1 W, 2 W, 4 W, 8 W, 16 W, bypass
- Coverage, Vertical
- 150°
TRANSDUCERS
- Driver Protection
- Recommended high-pass protection 85 Hz with minimum 24-dB/octave filter
- Low-Frequency
- 1 × 2.25 in (57 mm) woofer
Included in Packaging
- (1) cutout template
