The ControlSpace EX-8ML is a compact Dante endpoint interface that expands microphone and control connectivity for conferencing and installed audio systems. Featuring 8 mic/line inputs with phantom power and GPIO ports, it integrates seamlessly with Bose ControlSpace EX processors and other Dante-enabled systems.
Designed for flexibility, the EX-8ML can be mounted under tables, above ceilings, or in racks, reducing cabling complexity and bringing inputs closer to the sources.
- 8 × mic/line analog inputs with phantom power
- GPIO for control integration (e.g., projectors, lighting, switches)
- Dante™ networking for low-latency, uncompressed digital audio
- Seamless integration with ControlSpace EX conferencing processors
- Compact form factor for discreet installation
- Power over Ethernet (PoE) for single-cable simplicity (audio + power + control)
Specifications
- Analog Inputs: 8 × balanced mic/line inputs (Euroblock), each with phantom power
- GPIO: 4 × logic I/O ports (configurable as input or output)
- Dante Networking: 8 × 8 channels @ 48 kHz / 24-bit
- Connections:
• 1 × RJ-45 Dante port (Primary/Secondary selectable)
• 8 × Euroblock mic/line inputs
• 1 × Euroblock GPIO (4 pins) - Power: PoE (IEEE 802.3af, Class 0)
- Dimensions (H × W × D): 41 × 220 × 125 mm (1.6″ × 8.7″ × 4.9″)
- Net Weight: ≈ 1.1 kg (2.4 lb)
- Mounting: Tabletop, wall, ceiling, or rack accessory brackets
