Bose Professional DM6CB DesignMax Ceiling Loudspeaker – Black

The Bose Professional DM6CW is a powerful 125-watt in-ceiling loudspeaker from the DesignMax series, finished in white. It combines a 6.5-inch woofer with a 1.25-inch compression driver in a coaxial two-way design, delivering clear, impactful full-range sound for both background and foreground music. With wide coverage, high output, and a discreet low-profile design, the DM6CW is ideal for commercial installations in restaurants, retail, offices, hospitality venues, and houses of worship.

Key Features

• Passive full-range loudspeaker (requires external amplifier)
• 6.5″ woofer + 1.25″ compression driver in coaxial two-way design
• Frequency response: 59 Hz – 20 kHz (–10 dB)
• Power handling: 125 W continuous / 500 W peak
• Maximum SPL: 108 dB continuous, 114 dB peak
• Coverage pattern: 125° × 125° wide dispersion
• Integrated 70/100V transformer with 8 Ω bypass operation
• Paintable magnetic grille for seamless ceiling integration
• Low-profile ABS baffle with powder-coated steel grille

Specifications

• Frequency Range (–10 dB): 59 Hz – 20 kHz
• Coverage Pattern: 125° × 125°
• Power Handling: 125 W continuous / 500 W peak
• Nominal Impedance: 8 ohms (with transformer bypass)
• Connections: Euroblock connector
• Enclosure: ABS baffle with powder-coated steel grille
• Color: Black
