The Bose Professional DM8SW is a compact surface-mount subwoofer from the DesignMax series, finished in white. Equipped with an 8-inch woofer, it extends low-frequency performance in distributed audio systems, delivering deep, punchy bass that complements DesignMax full-range models. Its discreet enclosure, modern design, and included QuickHold U-bracket make it easy to integrate into retail, hospitality, restaurants, and commercial spaces.
Key Features
- Passive subwoofer (requires external amplifier)
- 8″ high-excursion woofer
- Frequency response: 47 Hz – 200 Hz (–10 dB)
- Power handling: 100 W continuous / 400 W peak
- Maximum SPL: 103 dB continuous, 109 dB peak
- 70/100V transformer taps plus 8 Ω bypass operation
- Stylish, compact enclosure with white finish
- Includes QuickHold U-bracket for fast installation
- Ideal for use with Bose DesignMax full-range loudspeakers
Specifications
- Frequency Range (–10 dB): 47 Hz – 200 Hz
- Coverage Pattern: Omnidirectional (subwoofer)
- Power Handling: 100 W continuous / 400 W peak
- Nominal Impedance: 8 ohms (with transformer bypass)
- Connections: Euroblock connector
- Enclosure: ABS cabinet with powder-coated steel grille
- Color: White
