Boss AD-10 Acoustic Preamp Pedal

The Boss AD-10 Acoustic Preamp is a dual-channel preamp, DI, and effects processor designed to deliver studio-quality tone for acoustic guitar players in both live and recording environments.
Featuring BOSS’s advanced Acoustic Resonance technology, the AD-10 restores the natural warmth and depth lost when using piezo pickups, while onboard EQ, compression, and ambience effects provide total tone control. With dual inputs, looping, anti-feedback processing, and USB audio, it’s a complete acoustic performance and recording solution in one professional pedal.

Features:

• Professional Dual-Channel Acoustic Preamp – restores body resonance and natural tone
• Acoustic Resonance Processing: Recreates the warm, woody tone of a miked acoustic guitar
• Two Independent Channels: For dual instruments or pickup systems, each with dedicated EQ and effects
• Powerful 4-Band EQ: With variable low-cut filter per channel
• Studio-Grade Effects: Reverb, Delay, Chorus, and Ambience
• Onboard 80-Second Looper: Ideal for live solo performance
• Anti-Feedback Control: Automatically suppresses problematic frequencies
• Phase and Mute Switches: Enhance live performance control
• Memory Function: 10 user presets for saving custom setups
• Balanced XLR and ¼″ Outputs: Send to PA, mixer, or amplifier
• USB Audio Interface: Record directly to your computer or DAW
• Headphones Output: For silent practice or monitoring
• Compact Design: Fits easily on pedalboards or in gig bags
• Rugged Construction: Metal chassis built for stage durability

Specifications:

• Nominal Input Level: -10 dBu
• Input Impedance: 10 MΩ
• Nominal Output Level: -10 dBu (¼″ Out) / -20 dBu (XLR Out)
• Output Impedance: 1 kΩ (¼″) / 600 Ω (XLR)
• Frequency Response: 20 Hz – 20 kHz
• Effects: Reverb, Delay, Chorus, Ambience, Acoustic Resonance, Looper
• Controls: Acoustic Resonance, EQ, Comp, Effects, Memory, Looper
• Connectors: 2 × Inputs (¼″), 2 × Outputs (¼″), XLR Out, Phones, USB, Expression, DC In
• Power Supply: 9V Battery or PSA-series AC Adapter (optional)
• Current Draw: 250 mA
• Construction: Die-Cast Aluminum Enclosure
