Real 300W RMS with high-end sound quality
High Efficiency for incredible SPL to Size ratio
Coaxial transducer for unmatched spacial coherence
Next generation HSP Annular Ring Radiator HF
Audiophile grade crossover with Right-Phase topology
Birch plywood cabinet with smooth texture or varnish finish
Multi-functional yoke with dented ring for secured angles
Available in Black, White, and Natural colors
SPECIFICATIONS:
| Power handling (AES Standard) | 300W RMS / 1200W Peak |
| Nominal impedance | 8 ohms |
| Frequency response (-6dB half space, no EQ) | 95~22000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 12000Hz |
| Average Sensitivity (wideband 200~16000Hz) | 97dB/W/m |
| Calculated Maximum SPL / 1m | 122dB RMS / 128dB Peak |
| Nominal Directivity (-6dB) | 90º conical above 1200Hz |
| Recommended low cut filter | 90-130Hz 24dB/oct with subwoofer, Cannot run full range, mandatory subwoofer (iFIX13S or iFIX17S) |
| Low Frequency driver | 10” Coaxial CELTO Acoustique Ferrite magnet, 2.5” Voice coil |
| High Frequency driver | 1” exit (Coaxial) 1.7” HSP Annular Ring Radiator (High Strength Polymer) |
| Crossover | Passive mode only 1500Hz, 12dB/oct on LF, 18dB/oct on HF |
| Flying hardware | Integrated Multi-function Yoke |
| Connectors | Screw terminals with banana plug |
| Cabinet | CNC made with tongue and grove assembly 15 mm birch plywood |
| Finish | Smooth textured coating (Black and White colors) or Varnish finish (Natural and Oak colors) |
| Size (HxWxD) | 300x300x304mm net, 410x380x440mm gross |
| Weight | 12,5kg net, 14.5kg gross |
