- Real 500W RMS power capacity
- Natural sound and incredible holographic reproduction
- Optimized for smooth frequency response in and out axis
- Premium custom made Drivers
- Proprietary 80ºx50º rotatable Elliptic horn
- Birch plywood cabinet with tongue & groove assembly
- Touring grade soft touch gloss-free black painting
Power handling (AES Standard) | 500W RMS / 200W Peack
Nominal impedance | 8 Ohm
Frequency response (-6dB half space, no EQ) | 51~22000Hz
Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz
Average Sensitivity | 97dB/W/m (wideband 200~16000Hz)
Maximum Calculated SPL @ 1m | 123dB continuous / 129dB Peak
Nominal Directivity (-6dB) | 80° x 50° above 1200Hz
Recommended low cut filter | 40Hz 24dB/oct in full range mode,80-120Hz with subwoofer
Low Frequency driver | 12″ CELTO driver, 3” In / Out Voice coil
High Frequency driver | 1” exit CELTO ACD40, 1.7” Voice coil, HSP Annular Ring Radiator
Crossover | Passive mode only 1600Hz, 12dB/oct on LF, 18dB/oct on HF
Flying hardware | 12 M8 points
Connectors | 2x NEUTRIK SpeakON® NL4MP
Floor Monitor use | Yes, 2 symmetric angles
Pole mount | 35mm top hat (0° and 10° angles)
Cabinet | CNC made with tongue and grove assembly,15mm birch plywood
Finish | Black Textured Waterborne Coating
Size (WxHxD) | 356x620x345 mm
Weight | 20kg net, 25kg gross
