Real 800W RMS with accurate deep tones
CELTO woofer with trimmed chassis for ultra compact format
High Efficiency for incredible SPL to Size ratio
6 M8 Flying points for added versatility
Birch plywood cabinet with smooth texture or varnish finish
Available in Black, White, Natural and Oak colors
SPECIFICATIONS:
Power handling (AES Standard) | 800W RMS / 2800W Peak
Nominal impedance | 8 ohms
Frequency response (-6dB half space, no EQ) | 38~1200Hz
Manufacturing Consistency tolerance | ±2dB from 50 to 400Hz
Average Sensitivity (wideband 200~16000Hz) | 99dB/W/m
Calculated Maximum SPL / 1m | 128dB RMS / 134dB Peak
Nominal Directivity (-6dB) | omnidirectional in usage range
Low Frequency driver | 18″ CELTO 18EX900, Ferrite magnet, 3.6” Voice coil
Crossover | No. Must use external DSP or dedicated iFIX amplifiers
Flying hardware | 6 M8 points
Connectors | Screw terminals with banana plug
Cabinet | CNC made with tongue and grove assembly, 18 mm birch plywood
Finish | Smooth textured coating (Black and White colors) or Varnish finish (Natural and Oak colors)
Size (HxWxD) | 482x596x600mm net, 660x550x690mm gross
Weight | 32kg net, 38kg gross
