VERSATILE HIGH OUTPUT / SIZE RATIO CABINET
Real 700W+110W RMS power capacity
For audiences up to 30,000 persons
Up to 16 speakers per array with 12 times safety standard
Premium Neodymiumd Aquaplased TC4 diaphragm for ultra smooth HF reproduction
Versatile and easy to use cable-free rigging system
Proprietary Isophase Wave-Shaping Acoustic Coupler
Touring grade Rubberized PolyUrea finish
SPECIFICATIONS
| Power Handling (AES Standard) | 700W RMS LF + 110W RMS HF / 2800W Peak LF + 440W Peak HF |
| Nominal impedance | 8 ohms LF, 16 ohms HF |
| Frequency response (-6dB half space, no EQ) | 50~18000Hz with full range preset |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity | 99dB/W/m LF, 109dB/W/m on HF |
| Maximum Calculated SPL @ 1m | 130dB RMS / 136dB Peak |
| Nominal Directivity (-6dB) | 100º H x 15º V per cabinet (total vertical directivity depends on the array setup) |
| Recommended low cut filter | 80-120Hz 24dB/oct with subwoofer |
| Low Frequency driver | Custom 2×10″ CELTO Acoustique, Neodymium magnet, 2.5” In/Out Voice coil |
| High Frequency driver | 1.5” exit CELTO Acoustique, Neodymium magnet, 2.8” Ferrofluid Voice coil, Aquaplased TC4 diaphragm |
| Crossover | Bi-amp mode only with external DSP processor, 1000Hz, 24dB/oct on LF and HF |
| Flying hardware | Cable-free Integrated aluminum rigging system |
| Connectors | 2x NEUTRIK Speakon NL4MP (1+/1- LF Input, 2+/2- HF Input) |
| Floor Monitor use | No |
| Pole mount | Yes with mounting adapter |
| Cabinet | CNC made with tongue and grove assembly, 15mm premium outdoor grade Baltic birch plywood |
| Finish | Touring grade Rubberized PolyUrea coating |
