Highlights
- Universal DMX controller capable of handling all the complexities of today’s lighting fixtures
- Easily control up to 12 intelligent lights with up to 32 channels each
- Includes 384 channels of DMX control and 30 banks of 8 scenes for a maximum of 240 scenes
- Enhance light shows with 6 sets of chase effects containing 240 scenes
- Increase effects with fog and strobe control, beat activation, tap-sync and auto run
- Increase flexibility with MIDI compatibility, DMX polarity selector and assignable pressure-sensitive joystick
- Conveniently mounts using the 4-space (4U) mounting rack
Specifications
- DMX Channels:384
- DMX Connectors:3-pin XLR
- Rackmount:4U
- Input Voltage:9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz)
- Weight:7.3 lb (3.3 kg)
- Size:19 x 7 x 2.8 in (483 x 178 x 71 mm)
- Approvals:CE
- Rackmount: 4U
What’s Included
- External power supply
- Quick Reference Guide
- Warranty card
