Citronic – CEQ215 DUAL 15 – Band Graphic Eq

The CEQ215 is a 19″ rack mounted dual 15-band graphic equaliser, which allows the adjustment of labelled frequencies via the individual cut/boost faders. Up to 12dB of cut or boost for frequencies ranging from 25Hz to 16kHz for accurate audio spectrum control.

Features:

• 2 x 15-band 2/3 octave ISO spacing
• RF filtered servo-balanced inputs
• Constant Q each band
• Bypass switch for EQ comparison
• Low-cut switch each channel
• Gain control each channel
• LED VU meters
• 19″ rackmount 1U

Specifications:

• Power supply: 115/230Vac, 50/60Hz (IEC)
• Frequency response: 20Hz-20kHz
• Input impedance : balanced: 40k Ohms
• Input impedance : unbalanced: 20k Ohms
• Output impedance : bal/unbal: 330 Ohms
• Channel separation: >50dB
• Signal to noise ratio: >102dB
• THD: 0.005%
• Dimensions: 482 x 44 x 138mm
• Weight: 2.0kg
