- Mix your show like a pro
- Optimize every detail of your sound
- Room-filling coverage
- Super-quick setup
- Single-trip portability
- Available in black or white
Specifications
| Frequency response (-3 dB)1 | 51 Hz to 20 KHz |
| Frequency range (-10 dB)1 | 45 Hz to 20 KHz |
| Maximum SPL2 | 123 dB |
Specifications |
|
| Coverage (H x V) | 120° x 40° |
| Amplifier rating | 1000 W |
| LF channel rating | 500 W |
| HF channel rating | 500 W |
| Crossover frequency | 200 Hz |
| Connectors | 4x XLR/TRS Combo Jack Line / Mic Input 1x 1/4″ TRS HI-Z input 2x XLR/TRS Combo Jack for Stereo Line Input 1x Stereo RCA Input 1x 3.5 mm Stereo Input 1x Wireless Stereo Bluetooth® Audio Input 1x 1/4″ Foot Switch Input 1x XLR MIX OUT Output 1x XLR AUX OUT Output |
| Enclosure | Sub: 15 mm plywood Column: Composite Pole: Aluminum Grille: Steel with black or white powder coat |
| Color: | Black or white |
| Dimensions (HxWxD): mm (in) | Sub: 448 x 332 x 432 (17.6 x 13.1 x 17) Column: 620 x 95 x 157 (24.4 x 3.7 x 6.2) Pole (2 pcs): 600 x 48 x 55 (23.6 x 1.9 x 2.2) |
| Net weight | Sub: 34.9 lb (15.8 kg) Column: 6.0 lb (2.7 kg) Pole (2 pcs): 3.1 lb (1.4 kg) Bag for column and pole: 1.9 (0.85 kg) |
| Shipping weight | 53.4 lb (24.2 kg) |
| Power consumption3 | 100-240 V AC, 50-60 Hz, 1.5-0.6 A |
1Half-space measurement using live DSP preset.
2Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
3Current rating is 1/8 power.
