Key Features:
• 800 W Class D Lightweight Amplifier
• Lightweight and Durable ABS Enclosure
• 2-way loudspeaker with EV8L 8” Woofer and DH2005
Titanium Compression Driver
• Rotatable High Frequency Waveguide with Two (2)
Coverage Patterns
• Bi-Amplified Design with 24dB/Octave Filter Slopes and
Transducer Protection
• Selectable 100Hz High Pass Filter for use with an
External Subwoofer
• XLR/TRS Combo Line Input
• XLR Microphone Input with Gain Control
• XLR Summed Output
• LED Indicators for Power On and Limit
• Pole Mount
• 45° Monitor Angle
Technical Specifications:
Freq. Response (-3dB): 60Hz–20kHz1
Freq. Range (-10dB): 48Hz–20kHz1
Max. Measured SPL: 126dB1, 3
Coverage (Horiz. x Vert.): 90° x 50°
Power Rating: 800W
LF Transducer:: (1) EV-8L, 204mm (8”) Woofer
HF Transducer: DH-2005, 25mm (1”)
Exit Compression Driver
Crossover Frequency: 1.8kHz
Connectors: (1) XLR Mic Input with Gain Control,
(1) XLR/TRS Combo Jack,
(1) XLR Link Output
Enclosure Material: ABS
Grille: 18GA Steel with Black Powdercoat
Mains Requirements: 100V: 80V–110V, 0.7A4, 50–60Hz
120V: 95V–132V, 0.6A4, 50–60Hz
230V: 190V–264V, 0.4A4, 50–60Hz
Dimensions (H x W x D): 457mm x 282mm x 264mm
(17.99” x 11.10” x 10.39”)
Net Weight: 8.6kg (19.0lbs)
Shipping Weight: 10.3kg (22.7lbs)
1. Full-Space
2. Half-Space
3. Typical maximum SPL value at one (1) meter over the usable frequency range. measure
with a pink-noise burst signal, using internal signal processing and amplifier driven to
peak output.
4. 1/8 power
