Active Bass Reflex Speaker
- 15″ Woofer with 3″ voice coil
- 1200 W Class-D amplifier
- Maximum level: 130 dB
- Frequency range: 40 – 120 Hz (+/- 10 dB)
- DSP functions: fully parametric 10-band EQ with variable filter characteristics, low-pass filter, polarity, level, delay, limiter, mute
- Filter presets: Front, Cardioid 1:1 vertical, Cardioid 1:1 horizontal, Remote
- Connection panel with 2x XLR/6.3 mm jack combo input, 1x Ethernet In, 1x Ethernet Thru, 2x XLR Thru and 1x XLR DSP Out
- M20 high stand flange
- 2 Handles
- Housing material: Birch plywood/MDF
- Dimensions (W x H x D): 480 x 535 x 675 mm
- Weight: 32.9 kg
- Colour: Black
2x HK Audio Linear 5 MKII 110 XA
Active Multifunctional Speaker
- With built-in 1200 W Class D power amplifier
- Speaker configuration: 1x 10″ LF + 1″ HF with 1.75″ voice coil
- Frequency range: 68 – 19,000 Hz (+/- 10 dB)
- Maximum level: 135 dB
- FIR crossover with 72 db/oct
- Remote controllable via internal DSP and network capability
- DSP functions: fully parametric 10-band EQ with variable filter characteristics, high-pass filter, low-pass filter, polarity, level, delay, limiter, mute
- Connector panel with 1 x XLR/6.3 mm jack combo input, 1x Ethernet In, 1x XLR Thru, 1x XLR DSP Out
- Switchable EQ (Flat, Monitor, Low Cut, Remote)
- Coverage angle: 80° x 60° (H x V, rotatable)
- Housing material: Birch plywood/MDF
- Rigging points: 3x M8
- DuoTilt stand flange
- 1 Handle
- Dimensions (W x H x D): 360 x 525 x 300 mm
- Weight: 14.9 kg
- Colour: Black
HK Audio Cover L5 MKII 115 Sub A
Weather Protection Cover
- For Linear 5 MKII 115 Sub A speakers
- Waterproof
- Transparent viewing windows
- Lockable access for handle and installation thread
- Colour: Black
2x HK Audio Cover L5 110 XA
Weather Protection Cover
- For Linear 5 MKII 110 XA speakers
- Waterproof
- Transparent viewing window
- Lockable access for handle and installation thread
- Colour: Black
