The Hybrid+ IM4.0P is a high-performance 4-channel power amplifier designed for professional audio installations and touring systems. Combining efficiency, power, and reliability, it delivers clean, high-headroom sound suitable for driving multi-zone PA systems, stage monitors, and line array configurations. Engineered with comprehensive protection circuitry and robust thermal design, the IM4.0P ensures consistent performance under demanding conditions.
Specifications
- Amplifier Type: Class D (high-efficiency switching design)
- Number of Channels: 4
- Power Output:
- Per Channel @ 8 Ω: 4 × 800 W RMS
- Per Channel @ 4 Ω: 4 × 1200 W RMS
- Bridged @ 8 Ω: 2 × 2400 W RMS (typical)
- Frequency Response: 20 Hz – 20 kHz (±0.5 dB)
- THD + N: < 0.05%
- Damping Factor: > 300 @ 8 Ω, 1 kHz
- S/N Ratio: > 105 dB
- Input Sensitivity: 0.775 V / 1 V / 1.4 V selectable
- Input Connectors: Balanced XLR × 4
- Output Connectors: Speakon NL4 × 4 & Binding Posts
- Cooling: Dual variable-speed fans with front-to-rear airflow
- Protection: Short circuit, overload, thermal, clip limiting, DC offset, soft start
- Power Supply: Universal SMPS, 100–240 V AC
Features
- True 4-channel amplifier—ideal for multi-zone or bi-amp systems
- Lightweight Class D design with high efficiency
- Fully protected for touring reliability
- Balanced XLR inputs and professional Speakon outputs
- Bridge-mode and stereo operation selectable per channel pair
- Front-panel signal, clip, and protect LEDs
Applications
- Live sound reinforcement
- Fixed installations and multi-zone venues
- Stage monitors and line array systems
- Rental and touring rigs
