SPEC
-
SPECS
- neck type
- AR3pc MapleSet-in (smooth heel) neck
- top/back/body
- Maple topOkoume backMaple body
- fretboard
- Bound Jatoba fretboardAcrylic & Abalone block inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- Gibraltar Performer bridge
- string space
- 10.5mm
- tailpiece
- Quik Change Classic tailpiece
- neck pickup
- Super 58 (H) neck pickupPassive/Alnico
- bridge pickup
- Super 58 (H) bridge pickupPassive/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D’Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- hardware color
- Gold
-
NECK DIMENSIONS
-
- Scale :
- 628mm/24.75″
- a : Width
- 43mm at NUT
- b : Width
- 56mm at 22F
- c : Thickness
- 20mm at 1F
- d : Thickness
- 22mm at 12F
- Radius :
- 305mmR
-
DESCRIPTION
-
-
SWITCHING SYSTEM
DESCRIPTION
-
CONTROLS
DESCRIPTION
-
OTHER FEATURES
Features
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
Gibraltar Performer bridge
The Gibraltar Performer bridge provides rich sustain and tuning stability.
The low positioned saddles promise comfortable playability.
2 Tri-sound switches
By giving each humbucker 3 different sounds, Tri-Sound switches expand your guitar’s versatility.
Hollow Body Construction
Quik Change Classic Tailpiece
The Quik Change Classic tailpiece enables faster and easier string changing.
Super 58 pickups
Super 58 pickups feature moderate output & vintage tone
Set-in neck
AR model features smooth heel for superb playability.
