Specifications
Neck Type : AS Artcore Nyatoh set-in neck
Top/Back/Side : Sapele top, Sapele back, Sapele sides
Fretboard : Bound Walnut fretboard, White dot inlay
Fret : Medium frets
Number of Frets : 22
Bridge : Gibraltar Performer bridge
String Space : 10.5mm
Tailpiece : Quik Change III tailpiece
Neck Pickup : Infinity R (H) neck pickup – Passive/Ceramic
Bridge Pickup : Infinity R (H) bridge pickup – Passive/Ceramic
Factory Tuning : 1E,2B,3G,4D,5A,6E
String Gauge : .010/.013/.017/.030/.042/.052
Hardware Color : Chrome
Neck Dimensions
Scale : 628mm
Width : 43mm at NUT
Width : 57mm at 22F
Thickness : 21mm at 1F
Thickness : 24mm at 9F
Radius : 305mmR
Body Dimensions
Length : 19 1/4″
Width : 15 3/4″
Max Depth : 2 5/8″
