SPECIFICATION
Neck Type : GRG7 Maple neck
Top/Back/Body : Quilted Maple Art Grain topPoplar body
Fretboard : Treated New Zealand Pine fretboardWhite dot inlay
Fret : Jumbo frets
Number of Frets : 24
Bridge : Ibanez F107 bridge
String Space : 10.5mm
Neck Pickup : Infinity R (H) neck pickup Passive/Ceramic
Bridge Pickup : Infinity R (H) bridge pickup Passive/Ceramic
Factory Tuning : 1E,2B,3G,4D,5A,6E,7B
String Gauge : .009/.011/.016/.024/.032/.042/.054
Nut : Plastic
Hardware Color : Black
NECK DIMENSIONS
Scale : 648mm/25.5″
a : Width : 48mm at NUT
b : Width : 68mm at 24F
c : Thickness : 20.5mm at 1F
d : Thickness : 22.5mm at 12F
Radius : 400mmR
