Specifications
Neck Type : GRGR, Maple neck
Top/Back/Body : Poplar Burl Art Grain top, Okoume body
Fretboard : Bound Purpleheart fretboard, Reveresed White Sharktooth inlay
Fret : Jumbo frets
Number of Frets : 24
Bridge : F106 bridge
String Space : 10.5mm
Neck Pickup : IBZ-6 (H) neck pickup, Passive/Ceramic
Bridge Pickup : IBZ-6 (H) bridge pickup, Passive/Ceramic
Factory Tuning : 1E,2B,3G,4D,5A,6E
String Gauge : .010/.013/.017/.026/.036/.046
NECK DIMENSIONS
-
- Scale : 648mm/25.5″
- a : Width : 43mm at NUT
- b : Width : 58mm at 24F
- c : Thickness : 19.5mm at 1F
- d : Thickness : 21.5mm at 12F
- Radius : 400mmR
