Features & Highlights
- 100 watt, 8″ active studio monitor / Self-powered. Amps matched to drivers; no external amp hassles
- Custom bi-amped, class A/B amplifiers / Provide high headroom and low distortion
- Heavy-duty enclosure / Durable
- Front-firing port / Allows placement flexibility (i.e. near walls) without interference from a rear-firing port
- Dedicated low and high frequency level adjustment controls / Allows you to optimize the monitor’s response to better match the room acoustics and the user’s personal preferences
- 8″ glass aramid composite woofer / Rigid and lightweight driver for optimal sound quality
- 1″ textile soft dome tweeter / Smooth high frequency response with excellent HF extension to 34.5 kHz
- Bass extension to 35 Hz / Excellent low frequency response for such a compact monitor
- Universal connectivity with XLR, 1/4″ TRS, and RCA inputs / Interfaces with just about any mixer and/or audio interface
- Volume control / Allows you to fine-tune your overall monitoring level
- System-optimized auto-limiter / Prevents unexpected peaks from damaging the speakers and provides consistency and clarity at high volumes
- Foam isolation pads on bottom / Protects the surface the monitors are sitting on and provides isolation for improved clarity
- 106 dB Max Peak SPL
Specifications
-
- Configuration: 2-Way
- System type: Active Studio Monitor
- Low-Frequency Transducer: 8″ Glass Aramid Woofer
- High-Frequency Transducer: 1″ Textile Soft Dome Tweeter
- Frequency Response (+/- 3dB): 42.5Hz – 28kHz
- Frequency Range (-10dB): 35Hz – 35kHz
- Crossover Frequency: 2.0kHz
- Average Beamwidth (Horizontal): 144 Degrees (900 Hz — 9 kHz)
- Average Beamwidth (Vertcal): 120 Degrees (900 Hz — 9 kHz)
- Max Peak SPL (With Limiter): 106 dB
- Max Average SPL (With Limiter): 103 dB
- Max Calculated SPL: 106 dB
- Amplifiers: Class A-B
- High Frequency Power Output (Watts): 25 Watts
- Low Frequency Power Output (Watts): 75 Watts
- Amplifier Distortion (THD+N): < 0.1% THD+N 20 Hz — 20 kHz (-3 dB Max Power)
- Input Impedance (Ohms): 10 KΩ Balanced / 7 KΩ Unbalanced
- Input Sensitivity: 2 dBu Balanced / -15 dBV Unbalanced
-
- SNR (Signal to Noise Ratio): > 100 dB
- Controls: System Volume -30 dB – +6 dB
- LF Level Adjust: (-2 dB, -1 dB, FLAT, +2 dB) Below 200 Hz
- HF Level Adjust: (-2 dB, -1 dB, FLAT, +1 dB) Above 2.0 kHz
- Indicators: Power
- Input Connectors: RCA, Balanced 1/4″ TRS, Balanced XLR
- Ouput Connectors: N/A
- AC Fuse (Slow Blow / Time Lag): 120 VAC (T2AL, 250 V) 240 VAC (T1AL, 250 V)
- Idle (Mute) AC Power Consumption: 10 Watts (NA SKU)
- Maximum AC Power Consumption: 184 Watts (NA SKU)
- Enclosure Construction: 15 mm MDF / High Impact Polystyrene
- Finish: Black Vinyl Wrap, Gold Chrome Electroplated Front Baffle
- Grille: N/A
- Hardware: Foam Isolation Pads
- Product Dimensions (H x W x D): 15.60″ (396 mm) x 10.82″ (275 mm) x 12.40″ (315 mm)
- Product Weight: 24.6 lb (11.16 kg)
