Features & Highlights
- 12″ Kevlar® Composite Woofer
- Bass extension to 23Hz with a max SPL of 119.9 dB
- Footswitch control enables/disables sub and crossover filter (footswitch not included)
- Redesigned cabinet with a lower profile and front-firing bass port
- Powerful, lightweight Class D amplification
- Optimized four-position crossover control
- Universal connectivity: XLR, 1/4″ TRS, and RCA inputs and outputs
- Polarity and input sensitivity controls
- Ground lift switch prevents ground loops
Specifications
-
- Configuration: Front Loaded, Vented Subwoofer
- System Type: Active Subwoofer
- Low-Frequency Transducer: 12″ Kevlar® Aramid Composite Woofer
- Frequency Response: 26Hz – 97Hz
- Max Peak SPL: 119.9 dB
- Amplifier: Class D
- Power Output (Continous): 220 Watts @ 1% THD+N @ 44Hz
- Signal to Noise Ratio: 92 dB
- Amplifier Distortion (THD + N): ≤ 0.3% @-3dB Of Max Power Output 29Hz-97Hz
- Input Impedance: 9.4 KΩ Balanced, 9.2 KΩ Unbalanced
- Ground Lift: On/Off
- HPF Bypass: With Footswitch Only
-
- Footswitch: Optional
- Indicators: Power/Standby
- Input Connectors: XLR L/R, 1/4″ TRS L/R, RCA L/R, 1/4″ Footswitch
- LFE Input: Balanced TRS
- Output Connectors: XLR L/R, 1/4″ TRS L/R, RCA L/R
- AC Power Input: Selectable 110V-120V / 220V0240V
- Enclosure: 18mm Reinforced MDF
- Finish: Black Vinyl Wrap, Baffle – Black Paint
- Hardware: EVA Isolation Pad
- Dimensions (H x W x D): (H x W x D): 16.375″ (416 mm) x 23.875″ (606 mm) x 14.375″ (365 mm)
- Weight: 62.5 Lb. (28.3 kg.)
