The Lane Pro LP15DSP is a 15″ powered loudspeaker equipped with advanced DSP (Digital Signal Processing) technology, designed to deliver exceptional sound quality and performance for professional audio applications.
- High Quality PP Composite Molded Cabinet
- M10 Mounting Thread
- Two Channel Amplifier
- Innovative DSP Processing
- 15″ Woofer
15″ Powered Loudspeaker
The LP15DSP is equipped with a 15-inch speaker driver, optimized to produce clear, powerful audio across a wide frequency range. This large driver ensures robust bass response and detailed high frequencies, making it suitable for a variety of sound reinforcement scenarios.
DSP Technology
The inclusion of DSP technology allows for precise control and optimization of the speaker’s audio output. This advanced processing capability enables users to tailor the sound to specific acoustic environments, achieving optimal clarity and balance.
Professional-Grade Construction
The speaker is built to withstand the rigors of professional use, featuring a durable ABS enclosure and components that can handle demanding performance requirements. Whether used in live sound, DJ setups, or installations, the LP15DSP is engineered for reliability and longevity.
Amplification
With its integrated power amplifier, the LP15DSP eliminates the need for external amplification, streamlining setup and ensuring seamless compatibility between the speaker and its built-in electronics.
Versatile Connectivity
The speaker is equipped with comprehensive connectivity options, including input ports for microphones, line-level signals, and other audio sources. This versatility makes it suitable for a wide range of audio setups and configurations.
User-Friendly Controls
The LP15DSP features intuitive controls for adjusting parameters such as EQ settings, volume levels, and DSP presets, allowing users to fine-tune the sound to their exact preferences.
The Lane Pro LP15DSP stands as a professional-grade powered loudspeaker that combines high-performance audio reproduction, sophisticated DSP processing, and rugged construction, making it an ideal choice for demanding sound reinforcement applications in professional settings.
Specifications
Acoustical Specifications
| Frequency Response | 46 Hz – 20 KHz |
| Max Spl @ 1m | N/A |
| Horizontal Coverage Angle | 90° |
| Vertical Coverage Angle | 60° |
Transducers
| Compression Driver | 1 X 1.75” Titanium |
| Woofer | 1x 15” 8oz 3″ VC |
Input/Output Section
| Input Signal | 2x Bal/Unbal |
| Input Connectors | XLR, Jack, Auxiliary |
| Output Connectors | XLR |
| Input Sensitivity | -2 Dbu/+4 Dbu |
| Mic. Input Sensitivity | -32 Dbu |
Processor Section
| Crossover Frequencies | 2.6KHz (Variable) |
| Protections | Thermal, RMS |
| Limiter | Soft Limiter |
| Controls | Volume, Boost, Mic/Line |
Power Section
| Total Power | 700 RMS |
| High Frequencies | 600 RMS |
| Low Frequencies | 100 RMS |
Cooling Convection
| Connections | VDE |
Physical Specifications
| Cabinet/Case Material | PP Composite |
| Hardware | 2 X M10 |
| Handles | On Either Side, One on Top |
| Pole Mount/Cap | Yes |
| Grille | Steel |
| Color | Black |
Size
| Height | 710 mm |
| Width | 410 mm |
| Depth | 400 mm |
| Weight | 16 kg |
