SYSTEM REQUIREMENTS
macOS 12, 13, 14, 15 (latest update), iTunes 12 (latest update), Intel Core i5 or Apple M1, M2, M3, 4 GB RAM.
Windows 10, 11 (latest service pack), Intel Core i5 or equivalent CPU, 4 GB RAM.
Windows 10, 11 (latest service pack), Intel Core i5 or equivalent CPU, 4 GB RAM.
SUPPORTED AUDIO FORMATS
MP3, WAV, AIFF, Audio-CD, FLAC, Ogg Vorbis, non-DRM AAC
GENERAL
Monitor with 1280 x 800 screen resolution, USB 2.0, 1 GB free disc space. An internet connection and a graphics card which supports OpenGL 2.1 or higher are required to download and activate TRAKTOR software. Once installed and activated, all products can be used offline.
DIMENSIONS
486mm / 265mm / 59mm
19.13″ / 10.43″ / 2.32″
19.13″ / 10.43″ / 2.32″
HARDWARE SPECIFICATIONS
Mic Input: (1/4″ / 6.3 mm TRS) |
|
| Bit Resolution: | 24-bit |
| Sample Rate: | 44.1/48 kHz |
| Full Scale Level: | -30… -10dBU @ 1 kHz |
| DNR (a-weighted)@ 1 kHz: | 89dB |
| THD+N @ 1KHz: | <0.1 % |
| Frequency response: | 80Hz-20kHz is +0.0 / -1.3 dB low frequency cutoff |
Audio Outputs (D/A) |
|
| Channels: | 4 |
| Bit Resolution: | 24-bit |
| Sample Rate: | 44.1/48 kHz |
Main Outputs – 2 x stereo out (line and 1/8″ / 3.5 mm TRS) |
|
| Line Outputs (RCA) | |
| Maximum Output Level: | +12.0 dBu |
| DNR (a-weighted): | 90dB |
| THD+N: | <0.03% |
| Frequency Response: | 20Hz-20kHz +/- 1.0 dB |
| Crosstalk @ 1kHz: | -80 dB |
Headphone Output |
|
| Stereo headphone out (1/8″ / 3.5 mm TRS) | |
| Maximum Output Level: | 45 mW @ 33 Ohm load |
| DNR (a-weighted): | 98dB |
| THD+N: | <0.1% |
| Frequency Response: | 20Hz-20kHz +/- 1.0 dB |
| Crosstalk @ 1kHz: | -55 dB |
