SYSTEM REQUIREMENTS
macOS 12, 13, 14, 15 (latest update), iTunes 12 (latest update), Intel Core i5 or Apple M1, M2, M3, 4 GB RAM.
Windows 10, 11 (latest service pack), Intel Core i5 or equivalent CPU, 4 GB RAM.
Windows 10, 11 (latest service pack), Intel Core i5 or equivalent CPU, 4 GB RAM.
SUPPORTED AUDIO FORMATS
MP3, WAV, AIFF, Audio-CD, FLAC, Ogg Vorbis, non-DRM AAC
GENERAL
Monitor with 1280 x 800 screen resolution, USB 2.0, 1 GB free disc space. An internet connection and a graphics card which supports OpenGL 2.1 or higher are required to download and activate TRAKTOR software. Once installed and activated, all products can be used offline.
SUPPORTED DRIVERS
Core Audio, WASAPI, ASIO, DirectSound
DIMENSIONS
542 mm / 339 mm / 60.5 mm
21.34″ / 13.35″ / 2.38“
21.34″ / 13.35″ / 2.38“
HARDWARE SPECIFICATIONS
Audio Inputs (A/D) |
|
| Channels: | 4 Stereo |
| Sample Rate / Resolution | 96-kHz / 24-bit |
| Converter | Cirrus Logic CS5368 |
Line Inputs |
|
| DNR (a-weighted) | 110 dB |
| Frequency Response | 20 Hz – 20 kHz, +0.1/- 0.05 dB |
| THD+N | 0.002% |
Mic Input |
|
| DNR (a-weighted) @ 1 kHz | 104 dB |
| Frequency response | 20 Hz – 20 kHz, +0.04/- 2.7 dB |
Phono Inputs |
|
| Input Impedance | 48.5kΩ |
| DNR (a-weighted) @ 1 kHz | 78 dB |
Audio Outputs (D/A) |
|
| Channels | 2 Stereo |
| Sample Rate / Resolution | 96-kHz / 24-bit |
| Converter | Cirrus Logic CS4385 |
Line Outputs (XLR & 1/4″ Booth) |
|
| DNR (a-weighted) | 110 dB |
| Frequency Response | 20 Hz – 20 kHz, +0.4/- 0.2 dB |
| THD+N | 0.001% |
Line Outputs (RCA) |
|
| DNR (a-weighted) | 110 dB |
| Frequency Response | 20 Hz – 20 kHz, +0.6/- 0.2dB |
| THD+N | 0.001% |
Headphone Output |
|
| Load Impedance | 33Ω |
| DNR (a-weighted) | 104 dB |
| Frequency Response | 20 Hz – 20 kHz, +0.4/- 0.3 dB |
SETUP EXAMPLES
External media players used on two inputs, and mixed on the TRAKTOR KONTROL S4. Speakers on main and booth outputs.
Simple TRAKTOR KONTROL S4 setup including a microphone. Speakers on main outputs.
DVS timecode DJ setup with two turntables, and speakers on main and booth outputs.
Add a TRAKTOR effects controller to expand your modulation control. Speakers on main and booth outputs.
