General
- Dual Piano and Dual Synth Layers
- OLED Display
- Seamless Transitions
- Split Point Crossfades
- 16 banks with 36 programs – 576 locations
- Organize for programs
- Organize for programs
- Live Mode – 6 Live programs
- Global Transpose: +/- 6 semitones
- Global Fine-tune: +/- 50 Cents
- Program Transpose: +/- 6 semitones
- 88 or 73-note Triple Sensor keybed with grand weighted action
- Selectable split point with LED indication (9 locations)
- Nord Triple Pedal 2 included
- MIDI over USB
Piano Section
- 2 independent Layers
- 2 GB memory for Piano sounds
- All sounds can be replaced using Nord Sound Manager (Mac/Win)
- 120 Voice Polyphony
- Categories: Grand, Upright, Electric, Digital/Layer, Clav/Harpsichord and Misc
- 3 Selectable Keyboard Touch Curves (Heavy, Medium, Light)
- Piano Timbre controls with custom settings for Electric Pianos and Clavinet
- String Resonance for acoustic Grand Pianos and Uprights
- Pedal Noise when used with Nord Triple Pedal 1, Nord Triple Pedal 2 or Nord Single Pedal 2 on acoustic and electric pianos
- Dynamic Compression
- Unison functionality
Sample Synth Section
- 2 independent Layers
- 1 GB memory for Nord Sample Library
- Amp envelope with Attack, Decay/Sustain and Release controls
- Vibrato with Rate/Amount, Delay, button or pedal
- Unison with 3 amounts
- Mono, Legato and Glide
- Octave transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)
Effects Section
- Mod 1: Tremolo, Pan 1 (Soft), Pan 2 (Hard), Spin, Wah, Ring Modulator (controllable via optional pedal)
- Mod 2: Phaser 1, Phaser 2, Flanger, Chorus 1, Chorus 2, Vibe, Spin. Stereo/Mono options for each effect
- Equalizer: Per Layer or Global, 3-band with sweepable mid (200 Hz – 8 kHz)
- Amp: Twin, JC and Small. Each with Alternate Tone option
- Compressor: Per Layer or Global, Amount control
- Delay: Per Layer or Global, Tempo, Feedback and Mix (Dry/Wet) controls, Ping Pong with 3 amount options, Tap-Tempo, Feedback Filter (HP/LP/BP), Flam
- Reverb: Global Reverb with Dry Wet amount optionally controllable per Layer. Spring, Booth, Room, Stage, Hall and Cathedral Reverb types, each with optional Pre-Delay, Chorale and Bright/Dark modes.
- Group mode for Effects
Connections
- 2 Audio outputs L & R – ¼”, 6,35 mm jacks, unbalanced
- 1 Monitor input – 1/8″, 3,5 mm stereo jack
- 1 Headphone output – ¼”, 6,35 mm stereo jack
- 1 Sustain Pedal input – ¼”, 6,35 mm jack. Compatible with Nord Triple Pedal or a momentary pedal
- Triple Pedal – 5 pin DIN connector. Use the included Nord Triple Pedal 2
- 1 Control/Volume Pedal input – ¼”, 6,35 mm TRS stereo jack.
- MIDI In, MIDI Out – 5 pin DIN connectors
- USB – type B connector – for transferring sounds and USB MIDI
- IEC C14 power connector
