GENERAL SPECIFICATIONS
| Nominal diameter | 457 mm/18 in |
| Power rating | 1500 W(AES) |
| Nominal impedance | 8Ω |
| Sensitivity | 96 dB |
| Frequency range | 30-1000 Hz |
| Chassic type | Cast aluminum |
| Magnet type | Ferrite |
| Magnet weight | 8.9 kg/312.5 oz |
| Voice coil diameter | 127 mm/5 in |
| coil material | Copper Wire |
| Former material | Glass fiber |
| Cone material | Paper |
| Surround material | Cloth |
| Suspension | Double |
| X-max | 9 mm/0.35 in |
| Gap depth | 14 mm/0.55 in |
| Voice coil winding width | 32 mm/1.26 in |
| Packing dimension WxDxH(mm) | 505 x 505 x 300 |
| Net weight | 24.8 kg/54.7 lb |
| Shipping weight | 26.9 kg/59.3 lb |
