General Specifications
| Throat Diameter | 35.5 mm / 1.4 in |
|---|---|
| Nominal Coverage Angle (HxV) | 60° x 40° |
| Cutoff Frequency | 400 Hz |
| Mounting Type | Bolt on |
| Material | Injection polymer A.B.S |
| Unit Weight | 1.2 kg / 2.65 lb |
| Shipping Weight | 1.7 kg / 3.75 lb |
| Packaging Dimension (WxDxH) | 315x315x255 mm 12.4×12.4×10 in |
Mounting Information
| Overall Dimensions | Mount Height | 304 mm / 11.97 in |
|---|---|---|
| Mount Width | 304 mm / 11.97 in | |
| Depth | 217 mm / 8.54 in | |
| Mounting Dimensions | Rear Height | 262 mm / 10.31 in |
| Rear Width | 263 mm / 10.35 in | |
| Baffle Cutout Dimensions | Height | 265 mm / 10.43 in |
| Width | 265 mm / 10.43 in |
