General Specifications
| Throat Diameter | 50 mm / 2 in |
|---|---|
| Nominal Coverage Angle (HxV) | 90° x 55° |
| Cutoff Frequency | 500 Hz |
| Mounting Type | Bolt on |
| Material | Injection polymer A.B.S |
| Unit Weight | 0.8 kg / 1.76 lb |
| Shipping Weight | 1.3 kg / 2.87 lb |
| Packaging Dimension (WxDxH) | 340x260x150 mm 13.4×10.2×5.9 in |
Mounting Specifications
| Overall Dimensions | Mount Height | 234 mm / 9.21 in |
|---|---|---|
| Mount Width | 323 mm / 12.72 in | |
| Depth | 117 mm / 4.61 in | |
| Mounting Dimensions | Rear Height | 190 mm / 7.48 in |
| Rear Width | 265 mm / 10.43 in | |
| Baffle Cutout Dimensions | Height | 170 mm / 6.69 in |
| Width | 235 mm / 9.25 in |
