General Specifications
| Throat Diameter | 50 mm / 2 in |
|---|---|
| Nominal Coverage Angle (HxV) | 90° x 40° |
| Cutoff Frequency | 400 Hz |
| Mounting Type | Bolt on |
| Material | Injection polymer A.B.S |
| Unit Weight | 1.6 kg / 3.53 lb |
| Shipping Weight | 2.7 kg / 5.95 lb |
| Packaging Dimension (WxDxH) | 465x295x260 mm 18.3×11.6×10.2 in |
Mounting Specifications
| Overall Dimensions | Mount Height | 250 mm / 9.84 in |
|---|---|---|
| Mount Width | 450 mm / 17.72 in | |
| Depth | 230 mm / 9.06 in | |
| Mounting Dimensions | Rear Height | 202 mm / 7.95 in |
| Rear Width | 396 mm / 15.59 in | |
| Baffle Cutout Dimensions | Height | 205 mm / 8.07 in |
| Width | 400 mm / 15.75 in |
