General Specifications
| Throat Diameter | 50 mm / 2 in |
|---|---|
| Nominal Coverage Angle (HxV) | 60° x 40° |
| Cutoff Frequency | 400 Hz |
| Mounting Type | Bolt on |
| Material | Injection polymer A.B.S |
| Unit Weight | 2 kg / 4.41 lb |
| Shipping Weight | 2.5 kg / 5.51 lb |
| Packaging Dimension (WxDxH) | 465x295x260 mm 18.3×11.6×10.2 in |
Mounting Specifications
| Overall Dimensions | Mount Height | 448 mm / 17.64 in |
|---|---|---|
| Mount Width | 280 mm / 11.02 in | |
| Depth | 235 mm / 9.25 in | |
| Mounting Dimensions | Rear Height | 356 mm / 14.02 in |
| Rear Width | 232 mm / 9.13 in | |
| Baffle Cutout Dimensions | Height | 360 mm / 14.17 in |
| Width | 235 mm / 9.25 in |
