Powersoft X4 DSP+D 4-Channel Amplifier With DSP And Dante

The Powersoft X4 DSP+D 4-Channel Amplifier with DSP and Dante delivers advanced amplification with global three-phase power capability and flexible DSP. Built with an ARM Cortex A-8 processor and TI C6000 DSP platform, it provides seamless audio and professional-grade signal management. Users enjoy versatile routing and multi-stage equalization with raised-cosine, IIR, and FIR filters for refined sound control. Input delay up to 2 seconds and output delay up to 100ms enable precise timing. TruePower™ limiters, Active DampingControl™, and peak limiters ensure stable performance under any load.

The X4’s universal power supply supports Single Phase, Bi-Phase, or Three Phase operation from 85VAC to 440VAC. This design enables automatic power management for reliable performance without manual setup. Power Factor Correction (PFC) reduces inrush current and maximizes energy efficiency, eliminating the need for external power sequencers.

Equipped with analog and digital AES3 input channels and optional Dante™ networking, the X4 DSP+D offers unmatched connectivity. An advanced input backup system automatically switches channels if the primary signal fails, ensuring uninterrupted operation. Real-time monitoring includes load impedance, output power, and mains voltage displays accessible through ArmoníaPlus software and a dedicated Web App. Robust protections against DC, VHF, and clipping make the X4 DSP+D amplifier a reliable, high-performance choice for live sound and installed audio systems.

In conclusion, the Powersoft X4 DSP+D 4-Channel Amplifier with DSP and Dante stands as a benchmark in professional audio amplification. Its innovative features, including advanced DSP capabilities, flexible power options, and real-time monitoring, ensure exceptional sound quality and reliability. Designed for demanding environments, this amplifier meets the needs of live sound and installed systems, delivering consistent performance and unmatched versatility in every application.
