General specifications
Exit Throat Diameter
1.0 inch / 25 mm
Related Impedance
8 ohm
Program Power (watt)
100 W
Power handling capacity
50 W
Sensitivity
109 dB
Frequency range
1200 – 20000 Hz
Diaphragm Material
Mylar
Suspension Material
Polyester
Suspension Design
Flat
Minimum Impedance (ohm)
6.50 ohm
Voice Coil Diameter
1.75 inch / 44 mm
Voice Coil Winding Material
Edgewound Aluminum
Voice Coil Former Design
Straight – Kapton
Number of layers
1
Kind of layers
outside
Flux Density
1.8 T
Phase Plug Design
2 slot
Phase Plug Material
PP Composite
Magnetics
Neodymium
Thiele – small parameters
Bl factor (Bl) (T x m)
7.50 T x m
Mounting information
Overall diameter
85 mm / 3.35 inches
Overall height
43 mm / 1.69 inches
Mounting
2 x 6 mm threaded holes at 90°
Standard compliance
Safety agency
CE compliant
Size / Weight
Weight
0.85 kg / 1.87 lbs
Shipping information
Package Height
65 mm / 2.56 inches
Package Width
111 mm / 4.37 inches
Package Depth
113 mm / 4.45 inches
Package Weight
0.89 kg / 1.96 lbs
