Samson SAMS-S ZONE 4-Input / 4-Zone Stereo Zone Mixer

The Samson S-Zone is a professional 4-input, 4-zone stereo mixer designed for commercial and installation applications. It allows independent routing of multiple stereo sources to up to four separate zones, making it ideal for restaurants, retail stores, gyms, and hospitality venues where different audio programs or volume levels are required in different areas.

Key Features:

• 4 stereo line inputs with individual level controls
• 4 stereo output zones with independent volume and routing controls
• Front-panel headphone jack with zone selection for monitoring
• Balanced XLR and unbalanced RCA outputs per zone
• Rear-panel DIP switches for mono/stereo operation per zone
• Rackmountable 1U metal chassis for professional installations
• Ideal for multi-room background music and paging systems

Specifications:

• Inputs: 4 x Stereo RCA
• Outputs: 4 x Balanced XLR + 4 x Stereo RCA
• Frequency Response: 20Hz–20kHz
• THD: < 0.005%
• Signal-to-Noise Ratio: > 90 dB
• Power: 230V AC, 50Hz
• Construction: Solid steel 1U rackmount chassis
