Key Specifications:
-
System Type: Passive
-
Configuration: 2-Way (Dual 15″ LF + HF Compression Driver)
-
Frequency Response (±3dB): 45Hz – 18kHz
-
Frequency Range (-10dB): 40Hz – 20kHz
-
Sensitivity (2.83V/1m): 101dB
-
Maximum SPL @1m: 135dB
-
System Rated Impedance: 4Ω
Transducers:
Low Frequency (x2):
-
Size: 2 × 381mm (15″)
-
Voice Coil Size: 65mm (2.5″)
-
Rated Impedance: 2×8Ω
-
LF Power (AES2-2012): 2×350W
High Frequency:
-
Driver Type: Compression Driver
-
Voice Coil Size: 44mm (1.75″)
-
Diaphragm Material: Titanium
-
Exit Size: 25mm (1″)
-
HF Power (AES2-2012): 40W
-
Nominal Coverage (H×V): 90° × 60°
Power Handling:
-
Continuous Power (RMS): 700W
-
Programme Power: 1400W
-
Peak Power: 2800W
-
Crossover Frequency: 2.2kHz
Enclosure:
-
Material: MDF
-
Finish: Black paint
-
Grille: Steel
Dimensions (Unpacked):
-
Height: 1058mm (41.7″)
-
Width (Front): 444.5mm (17.5″)
-
Width (Rear): 245.3mm (9.7″)
-
Depth: 429mm (16.9″)
Weight:
-
Net Weight: 34.5kg (75.9 lbs)
-
Gross Weight: 38.9kg (85.6 lbs)
Connections & Hardware:
-
Input Connectors: 2 × NL2 combo jack (speakON & 1/4″ jack compatible)
-
Mounting: Dual-angle (0° or 10°) 35mm pole socket
-
Handles: 2 carry handles
The IMPACT-X215 is designed for high-output full-range sound reinforcement, making it ideal for live performances, DJ setups, and large venues requiring powerful, clear audio.
