SPECIFICATIONS
| Model Name | WLA-28X |
|---|---|
| System Type | 2 x 8” Two-way |
| Frequency Response (+/-3 dB) | 65 Hz-20 KHz |
| Sensitivity (2.83 v / 1 m) | 101 dB |
| Calculated Maximum SPL @1 m | 133 dB |
| Nominal Coverage (H x V) | 100°x10° |
| Power: Continuous / Programme / Peak |
Passive: 400 W / 800 W / 1600 W Bi-amp LF: 400 W / 800 W / 1600 W Bi-amp HF: 90 W / 180 W / 360 W |
| Rated Impedance ( Ω ) | Passive: 16 Ω Bi-amp LF: 16 Ω ; Bi-amp HF: 16 Ω |
| HF Diaphragm Material | Titanium |
| HF Magnet Material | NdFeB |
| LF Magnet Material | Ferrite |
| LF Frame Material | Aluminium |
| HF Coil Size (inches/mm) | 3.0” (75 mm) |
| LF Coil Size (inches/mm) | 2.0” (51.6 mm) |
| Crossover Frequency | 1.7 KHz |
| Cabinet Type | Trapezoid |
| Enclosure Material and finish | 18 mm / 15 mm Plywood |
| Enclosure Colour | Black paint |
| Grille Material & Finish | 1.5 mm Steel |
| Connectors | Neutrik NL4MP |
| Hardware | Integral side plate adjustable rigging 0°-10° |
| Cabinet Dimensions HxWxD(mm) | 250 x 760 x 463.2 mm |
| Packed Dimensions HxWxD(mm) | 320 x 830 x 534 mm |
| Net Weight (Kg) | 29.5 Kg |
| Gross Weight (Kg) | 32.0 Kg |
