Yamaha MG06 Mixing Console

Yamaha MG06 Desk Mixer

Compact, high-quality desktop mixer for live sound, recording, and streaming applications.

The Yamaha MG06 is a portable 6-channel analog mixer designed for musicians, podcasters, content creators, and small PA systems. Featuring Yamaha D-PRE™ Class-A microphone preamps, balanced outputs, and a rugged metal chassis, the MG06 delivers professional sound quality in an ultra-compact format.

Key Features

High-Quality D-PRE™ Microphone Preamps

• 2 × XLR/TRS combo mic/line inputs

• Yamaha D-PRE™ Class-A preamps with inverted Darlington circuit

• Clear, natural sound with low noise and high headroom

• +48V phantom power for condenser microphones

• 26 dB PAD switch for handling high-level input sources

Flexible Input Configuration

• 6 total inputs

  • 2 mono mic/line channels

  • 2 stereo line channels

• Ideal for microphones, instruments, keyboards, DJ gear, and playback devices

Channel EQ & Filtering

• 2-band EQ on mono channels

• High-pass filter (80 Hz, 12 dB/oct) to reduce unwanted low-frequency noise

• Peak LED indicators on mono channels for easy level monitoring

Professional Output Connectivity

• Balanced stereo XLR outputs

• Balanced stereo TRS outputs

• Dedicated ¼″ headphone output for monitoring

• Clean, transparent signal path with THD as low as 0.003%

Compact, Portable & Durable Design

• Rugged powder-coated steel chassis

• Ultra-lightweight and space-saving

• Ideal for desktop use or mobile setups

• Powered by external DC 12V adapter

Ideal Applications

• Small live sound systems

• Podcasting and streaming

• Home recording and content creation

• Keyboard and vocal sub-mixing

• Mobile musicians and presenters

Specifications

MG06

General

• Mixer Type: Analog

• Channels: 6 total

  • 2 mono mic/line

  • 2 stereo line

• Stereo Bus: 1

Inputs

• Mic/Line Inputs:

  • 2 × XLR/TRS combo (balanced)

  • +48V phantom power

  • PAD: 26 dB

• Stereo Line Inputs:

  • 2 × ¼″ TRS

Channel Processing

• EQ (Mono Channels): 2-band

• High-Pass Filter: 80 Hz, 12 dB/oct

• Peak LED Indicator: Yes (mono channels)

Outputs

• Stereo Outputs:

  • Balanced XLR

  • Balanced ¼″ TRS

• Headphone Output: ¼″ stereo jack

Audio Performance

• Total Harmonic Distortion:

  • Approx. 0.003% @ +18 dBu

• High-quality op-amps for clean, transparent audio

Power

• Power Supply: DC 12V

• Compatible Adapters: Yamaha PA-130 or MU-18

Physical

• Dimensions (W × D × H):

  • 149 × 202 × 62 mm

• Net Weight:

  • Approx. 0.9 kg (1.98 lb)

• Chassis: Powder-coated steel
