Yamaha MG06X Mixing Console

Yamaha MG06X 6-Channel Mixing Console With Effects

Compact, durable, and feature-rich, the Yamaha MG06X is a 6-channel analog mixer with built-in SPX digital effects, designed for live performance, streaming, podcasting, and small PA or recording setups. Despite its compact size, it delivers studio-quality sound using Yamaha’s renowned D-PRE™ Class-A microphone preamps.

High-Quality Sound in a Compact Design

The MG06X features Yamaha D-PRE™ mic preamps with an inverted Darlington circuit, providing clean headroom, low distortion, solid bass response, and smooth high frequencies. This ensures natural and transparent sound whether you’re using microphones or line-level sources.

Built-In SPX Digital Effects

The MG06X includes high-grade SPX digital effects, allowing you to add professional polish without external processors. Effects include reverb and delay, ideal for vocals, acoustic instruments, and spoken-word applications.

Flexible Input Configuration

• 6 total inputs

  • 2 mono mic/line channels

  • 2 stereo line channels

• 2 XLR/TRS combo inputs with:

  • +48V phantom power for condenser microphones

  • PAD switch for high-level signals

• Stereo inputs for keyboards, media players, DJ gear, or playback devices

Practical Channel Controls

• 2-band EQ on mono channels for tonal shaping

• High-pass filter (HPF) to reduce low-frequency rumble

• Simple, intuitive layout for fast setup and operation

Reliable Build for Any Environment

Housed in a rugged metal chassis, the MG06X is built for long-term reliability in both fixed installations and mobile use. Its compact and lightweight design makes it easy to transport and set up anywhere.

Ideal Applications

• Live performances and rehearsals

• Podcasting and streaming

• Home recording and content creation

• Small PA systems

• Keyboard and vocal sub-mixing

Specifications

MG06X

General

• Mixer Type: Analog

• Channels: 6 total

  • 2 mono mic/line

  • 2 stereo line

• Stereo Bus: 1

Inputs

• Mic/Line Inputs:

  • 2 × XLR/TRS combo (balanced)

  • +48V phantom power

  • PAD switch on mono inputs

• Stereo Line Inputs:

  • 2 × line inputs (TRS)

Channel Processing

• EQ (Mono Channels): 2-band

• High-Pass Filter (Mono Channels): Yes

• Built-in Effects:

  • SPX digital effects

  • 6 effect programs (reverb & delay)

Outputs

• Main Outputs:

  • Balanced XLR

• Headphone Output: Stereo

Audio Performance

• D-PRE™ mic preamps with inverted Darlington circuit

• Clean, low-distortion signal path

Power

• Power Supply: External DC adapter

Physical

• Dimensions (W × H × D):

  • 149 × 62 × 202 mm

  • (5.9″ × 2.4″ × 7.9″)

• Net Weight:

  • 0.9 kg (1.98 lbs)

• Chassis: Metal
