Specifications
Size/Weight
- Width: 1333mm
- Height: 160mm
- Depth: 404mm
- Weight: 13.8 kg
Control Interface
- Number of Keys: 88
- Keyboard Type: GHS Keyboard
- Initial Touch: Yes
- Aftertouch: No
Tone generator
- Tone Generator: Motion Control Synthesis Engine AMW2
- Maximum Polyphony: AWM2
- Multi Timbral Capacity: 16 Parts (internal); Audio Input Parts (A/D* USB*) stereo Part
- Wave: Preset
- Performance: 2227
- Filter: 18 types
- Effects: Reverb x 12 types; Variation x 88 types; Insertion (A B) x 88 types2; Master Effect x 26 types 2 A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands); 1st part EQ (3 bands); 2nd part EQ (2 bands)
Other
- Controllers: Master Volume; AD Input Gain knob; USB Volume; Pitch Bend wheel; Modulation wheel; Control Sliders x 4; Knobs x 4; Super Knob; Data dial
- Display: 7″ TFT Color Wide VGA LCD touch screen
- Connectors: [USB TO DEVICE]; [USB TO HOST]; MIDI [IN]/[OUT]; FOOT CONTROLLER [1]/[2]; FOOT SWITCH [ASSIGNABLE]/[SUSTAIN]; OUTPUT [L/MONO]/[R] (6.3 mm; standard phone jacks); [PHONES] (6.3 mm; standard stereo phone jack); A/D INPUT [L/MONO]/[R] (6.3 mm; standard phone jacks)
- Power Consumption: 16 W (when using PA-150B AC adaptor)
- Accessories: AC adaptor (PA-150B or an equivalent recommended by Yamaha); Owner’s Manual; Cubase AI Download Information *May not be included depending on your area. Check with your Yamaha dealer.
- Live Sets: Preset
Performance Recorder
- Note Capacity: Approx. 130000 notes
- Storage Size: Approx. 520000 notes (for Patterns) and approx. 520000 notes (for Songs)
- Note Resolution: 480 ppq (parts per quarter note)
- Tempo (BPM): 5 – 300
- Songs: 128 songs
- Tracks: 16 Sequence tracks
- Recording type: Real time replace; Real time overdub; Real time punch in/out
- Patterns: 128 patterns
- Arpeggio: Parts
- Sequence formats: MODX original format; SMF formats 0 and 1
